Products > Lab Two Roll Mills -- Electrically Heating Test Roll Plastic Mixer

The Two Roll Mill is ideal for mixing a wide range of plastic materials including PVC, additives, etc.

Feature:

With optimum precision and safety performance, the machine is completely closed with sturdy frame, optimum precision, neat shape and small space required. It is the optimum design for Lab and technical center.
The test rolls is made of alloy steel, surface treatment and hardened of test roll by precision grind and chrome plated.
Each roll is available drove by variable speed individually. Variable speed drive is ranged from 8 RPM to 26 RPM. Digital read tachometers display RPM clearly for both rollers.
Equipped with knee-push activated emergency safety switch and unique design of pulling limit switch by shaft stops the operation.
That will ensure its optimum safety performance.
It is simple to adjust gap between two rolls by micro-regulator with scale ring
Cabinet design with anti-vibrating rubber at the bottom of machine's mainframe, to assure its stability and safety. Not necessary a complicated working for installation. It is easy to install and move.
Test rolls are electrically heating. Max. temperature is 220ºC

MODEL : CR-H-N410/CR-H-N615
Electric heating type

Model	CR-H-N410	CR-H-N615
Size of Roll	4" (Diameter) x 10" (Length)	6" (Diameter) x 15" (Length)
Rotation speed ratio	Each roll is available drove by variable speed individually. Variable speed drive is ranged from 8 RPM to 26 RPM.
Adjustable nip Clearance	Manual adjustment by using indicator
Housing of Bearing	Equipped with Tapered Roller Bearing and sealed housing
Safety Device	1. Knee-push activated emergency safety switch set in front/back of the frame. Use knee push the red safety switch to stop the operation. 2. Unique design of pulling limit switch by shaft stops the operation.
Temp. Control	Electrically Heating / Max. 220ºC
Temp. Tolerance for Surface	± 5ºC
Temp. Control Device	Use high precision and multi-function P.I.D. digital controller. Temperature is displayed digits.
Operation Control	Centralize operation in one panel. It is easy to operate and monitor temp. controller, tachometer, push button switch, voltage meter, ampere meter, etc. in one panel.
Collecting Tray	Made of Stainless Steel
Voltage Requirements	220V/380V/415V/440V/480V/ 3 Phase
Power	Motor: 1.5kw x 2 sets Heater: 4 kw x 2 Sets	Motor: 2.2kw x 2 sets Heater: 6 kw x 2 Sets
Machine Dimension	1350mm x 700mm x 1450mm (LxWxH)	1520mm x 950mm x 1550mm (LxWxH)
Weight	N.W.: 500 kgs G.W.: 700 kgs	N.W.: 1100 kgs G.W.: 1300 kgs
